Compact patient monitor PM-8B
Electrical Specification: 100-240v AC, 50/60Hz, Max Input Power: 70VA Battery: 11.1V 2200mAh rechargeable lithium battery Standard configuration: SpO2, PR, NIBP, ECG, RESP, TEMP Optional Configuration: Nellcor SpO2, E
In Stock
SKU: EMH-EC48D499
Individual OrdersSuitable for home or personal requirements
Professional SupplyFor clinics, labs and healthcare teams
Bulk & Trade OrdersFor hospitals, resellers and institutions
✓Model confirmationVerify specifications and accessories
✓Flexible quantitiesRequest one unit or a larger quantity
✓Delivery planningShare your location for available options
The displayed information is a starting reference. Final model, accessories, availability, price and delivery terms are confirmed before purchase.
Overview
- Electrical Specification
- 100-240v AC, 50/60Hz,
- Max Input Power
- 70
- VA Battery
- 11.1V 2200mAh rechargeable lithium battery
- Standard configuration
- SpO2, PR, NIBP, ECG, RESP,
- TEMP Optional Configuration
- Nellcor SpO2, ETCO2,
- Package Include
- 1 x Main Unit 1 x Li-Battery 1 x Power line 1 x Earth wire 1 x User’s Manual 1 x Blood oxygen probe (for SpO2, PR) 1 x Blood pressure cuff (for NIBP) 1 x ECG cable (for ECG, RESP) 1 x Temperature probe (for
- Temperature) Technical Specification
- ECG Input - 3/5 wire ECG cable Lead section - I II III aVR, aVL, aVF, V Gain selection - *0.25, *0.5, *1, *2, Auto Sweep speed - 6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s Heart rate range - 15-30bpm Calibration - ±1mv Accuracy - ±1bpm or ±1% (select the bigger data) NIBP - Test method - Oscillometer Philosophy - Adult, Pediatric and Neonate Measurement type - Systolic Diastolic Mean Measurement parameter - Automatic, Continuous measurement Measurement method Manual - mmHg or ±2% SPO2 Display Type - Waveform, Data
Measurement Range
0-100% Accuracy - ±2% (between 70%-100%) Pulse rate range - 20-300bpm Accuracy - ±1bpm or ±2% (select the bigger data) Resolution - 1bpm 2-Temperature (Rectal & Surface) Number of channels - 2 channels
Measurement Range
0-50℃ Accuracy - ±0.1℃ Display - T1, T2 Unit - ºC/ºF selection Refresh cycle - 1s-2s Respiration (Impedance & Nasal Tube) Measurement type - 0-150rpm Accuracy - ±1bm or ±5%, select the bigger data Resolution - 1rpm Packing Information Packing size - 25*17.5*24cm
